3000W Solar Power Solutions , Mppt Solar Management Unit 108x327.8x 41.6mm Size

Name: 3000W Solar Power Solutions Mppt Solar Management Unit 108x3278x 416mm Size
Brand: LionRock
Price: 1 USD

Brand Name : LionRock

Place of Origin : Dongguan China

Payment Terms : TT

Packaging Details : export packing

MOQ : negotiate

Price : negotiate

Delivery Time : negotiate

Model Number : MPPT

Power : 3000W

Input Voltage : 187~430Vdc (full power range), 100~430Vdc (voltage range)

Total Harmonic Distortion(THD) : <5% (full load); <10% (half load)

Ripple and Noise : <200mVpp, 20MHz bandwidth

Dimension : 108mm x 327.8mm x 41.6mm

Weight : 2.5kg

Contact Now

Maximum Power Point Tracking Solar Power Solutions

Features

- Max 98% efficiency, energy saving
- Modular design, compatible with Huawei 50A module system
- CAN communication
- Support hot-swap
- Wide temperature range
- Support voltage and current regulation
- Built-in fan cooling

Telecom DC Power System - MPPT

Power	3000W
Input Voltage	187~430Vdc (full power range), 100~430Vdc (voltage range)
Input Current	≤18A rms at nominal input, ≤21A rms at 185Vdc input
Total Harmonic Distortion(THD)	<5% (full load); <10% (half load)
Output Voltage	53.5Vdc (rated); 42~58Vdc (adjustable)
Ripple and Noise	<200mVpp, 20MHz bandwidth
Maximum Output Current	56.6±0.5A
Efficiency	≥95.5%@normal; ≥96.2% max efficiency, MPPT efficiency≥99%
Environment	−40 to +75oC (operating temp), +50 to +75oC (derating apply)
Dimension (W x D x H)	108mm x 327.8mm x 41.6mm
Weight	2.5kg
